9.1 What is Operational Semantics?🔗

Operational semantics explains how programs execute on an abstract machine, providing a precise mathematical account of program meaning.

In short: syntax describes how programs are written; semantics explains what they do.

In this lecture, we will define an operational semantics for Micro-OCaml and develop an interpreter for it along the way. The approach is to use rules to define a judgment:

e ⇒ v

This judgment reads: "expression e evaluates to value v."

9.2 Rules and Judgement🔗

In the context of operational semantics, the central idea is to describe program execution using rules that establish when a certain statement about a program is true. This statement is called a judgment.

The approach is to define these judgments using inference rules. Each rule tells you how to derive a valid judgment from simpler ones. In other words, rules specify how execution proceeds step by step.

By repeatedly applying such rules, we build a derivation tree whose root is the final judgment. This tree is a formal proof of how the program executes.

So, the key idea is:

• Judgments describe execution outcomes

• Inference rules define when those judgments are valid

• Derivations (rule applications) explain how a program runs step by step

9.3 Defining the Semantics with Inference Rules🔗

We use inference rules to define the judgment e ⇒ v. An inference rule has the form: \frac{H1 \quad H2 \quad ... \quad Hn} {C}

which reads: if hypotheses H1, H2, ..., Hn all hold, then conclusion C holds. Formally: H1 ^ H2 ^ ... ^ Hn ⇒ C.

For example, the classic syllogism: \frac{ \forall{}x(Man(x) \rightarrow{} Mortal(x)), Man(Socrates)} {∴ Mortal(Socrates)}

Inference rules are like Lego blocks: each rule is a small, well-defined piece that can be combined with others to build something larger. By applying these rules step by step, we construct bigger structures—first simple expressions, then more complex ones, and eventually entire programs. This process can be tedious, since every step must follow the rules precisely. But that discipline is exactly what makes it powerful: nothing is improvised, skipped, or altered—no “gluing” or “cutting corners.” Every result is built purely from valid rule applications. Because the rules can be applied recursively, they scale naturally from small examples to large programs. In this way, inference rules provide a systematic and reliable method for assigning meaning to programs of any size.

9.4 Micro-OCaml Expression Grammar🔗

The expression grammar for the language we will study (Micro-OCaml) is:

e ::= x | n | e + e | let x = e1 in e2

where x is a variable identifier and n is an integer literal.

The corresponding OCaml AST type is:

type id = string
type exp =
  | Ident of id           (* x *)
  | Num of int            (* n *)
  | Plus of exp * exp     (* e + e *)
  | Let of id * exp * exp (* let x = e1 in e2 *)

9.5 Rules of Inference🔗

match e with
| Num n -> n

match e with
| Plus (e1,e2) ->
    let n1 = eval e1 in
    let n2 = eval e2 in
    let n3 = n1 + n2 in
    n3

match e with
| Let (x,e1,e2) ->
    let v1 = eval e1 in
    let e2' = subst v1 x e2 in
    let v2 = eval e2' in
    v2

9.6 Derivations🔗

Example: Show that let x = 4 in x+3 ⇒ 7

Using the let-rule, we need to show 4 ⇒ 4 and x+3{4/x} ⇒ 7, i.e., 4+3 ⇒ 7. For the addition, we need 4 ⇒ 4, 3 ⇒ 3, and 7 is 4+3. Full derivation:

                  4 ⇒ 4    3 ⇒ 3    7 is 4+3
                  ----------------------------
      4 ⇒ 4              4+3 ⇒ 7
      ---------------------------------
         let x = 4 in x+3 ⇒ 7

9.7 Definitional Interpreter🔗

The style of the inference rules lends itself directly to implementation as a recursive function. Each rule becomes a match case:

let rec eval (e:exp) : value =
  match e with
    Ident x ->       (* no rule — free variables have no value *)
      failwith "no value"
  | Num n -> n
  | Plus (e1,e2) ->
      let n1 = eval e1 in
      let n2 = eval e2 in
      let n3 = n1 + n2 in
      n3
  | Let (x,e1,e2) ->
      let v1 = eval e1 in
      let e2' = subst v1 x e2 in
      let v2 = eval e2' in
      v2

Notice there is no rule for Ident x in the substitution-based semantics — by the time we evaluate a let body, all free variables have already been substituted away.

Derivation trees mirror interpreter call trees. For example, the derivation of let x = 4 in x + 3 ⇒ 7 has the same structure as the recursive evaluation calls made by the interpreter.

eval Num 4 ⇒ 4    eval Num 3 ⇒ 3    7 is 4+3
              ----------------------------
eval Num 4 ⇒ 4    eval (subst 4 "x" Plus(Ident("x"),Num 3)) ⇒ 7
-------------------------------------------------------------
    eval Let("x", Num 4, Plus(Ident("x"), Num 3)) ⇒ 7

Every step in the proof corresponds exactly to a recursive call in the evaluator.

9.8 Semantics Defines Program Meaning🔗

In operational semantics, we write

e ⇒ v

to mean that expression e evaluates to value v. This judgment holds if and only if there exists a proof (also called a derivation) demonstrating it.

• Proofs are derivations: they are structured trees where axioms appear at the leaves, and inference rules are applied step by step up to the root.

• No proof exists: if no derivation can be constructed, then there is no value v such that e ⇒ v.

• Construction is bottom-up: proofs are built from the leaves toward the root in a goal-directed manner, reflecting how evaluation proceeds.

From this, we define the evaluation function:

eval e = { v | e ⇒ v }

Since our semantics is deterministic, each expression e has at most one corresponding value v. Therefore, an expression e means exactly v.

In other words, the semantics assigns a precise mathematical meaning to every valid program: it tells us exactly what value the program computes.

9.9 Environment-style Semantics🔗

The substitution-based semantics is elegant but not close to how real interpreters work. An alternative is to use an environment.

• Substitution semantics: as we evaluate, we replace all occurrences of variable x with the value it is bound to (rewriting the AST)

• Environment semantics: as we evaluate, we maintain an explicit map from variables to values (like a symbol table), and look up variables as we encounter them

The environment-based approach is more efficient and closer to real implementations.

•(x)          = undefined

                  v          if x = y
(A, y:v)(x) =   A(x)        if x <> y and A(x) defined
                  undefined  otherwise

type env = (id * value) list

let extend env x v = (x,v)::env

let rec lookup env x =
  match env with
    [] -> failwith "undefined"
  | (y,v)::env' ->
      if x = y then v
      else lookup env' x

9.10 Semantics with Environments🔗

The environment semantics changes the judgment from e ⇒ v to:

A; e ⇒ v

where A is the current environment. The idea is that A provides values for the free identifiers in e.

let rec eval env e =
  match e with
    Ident x -> lookup env x
  | Num n -> n
  | Plus (e1,e2) ->
      let n1 = eval env e1 in
      let n2 = eval env e2 in
      let n3 = n1 + n2 in
      n3
  | Let (x,e1,e2) ->
      let v1 = eval env e1 in
      let env' = extend env x v1 in
      let v2 = eval env' e2 in
      v2

9.11 Adding Conditionals to Micro-OCaml🔗

We extend the language with boolean values, an eq0 test, and if expressions:

e ::= x | v | e + e | let x = e in e
      | eq0 e | if e then e else e

v ::= n | true | false

The OCaml types become:

type value =
  | Int of int
  | Bool of bool

type exp =
  | Val of value
  | ...          (* as before *)
  | Eq0 of exp
  | If of exp * exp * exp

let rec eval env e =
  match e with
    Ident x -> lookup env x
  | Val v -> v
  | Plus (e1,e2) ->
      let Int n1 = eval env e1 in
      let Int n2 = eval env e2 in
      let n3 = n1+n2 in
      Int n3
  | Let (x,e1,e2) ->
      let v1 = eval env e1 in
      let env' = extend env x v1 in
      let v2 = eval env' e2 in
      v2
  | Eq0 e1 ->
      let Int n = eval env e1 in
      if n=0 then Bool true else Bool false
  | If (e1,e2,e3) ->
      let Bool b = eval env e1 in
      if b then eval env e2
           else eval env e3

9.12 Adding Closures to Micro-OCaml🔗

We extend the language with first-class functions:

e ::= x | v | e + e | let x = e in e
    | eq0 e | if e then e else e
    | e e | fun x -> e

v ::= n | true | false | (A, λx.e)

A closure (A, λx.e) pairs a function body e (with parameter x) with the environment A at the time the function was created.

The OCaml types become:

type value =
  | Int of int
  | Bool of bool
  | Closure of env * id * exp   (* environment + parameter + body *)

type exp =
  | Val of value
  | If of exp * exp * exp
  | ...       (* as before *)
  | Call of exp * exp
  | Fun of id * exp

let x = 1 in
let f = fun y -> x + y in
let x = 2 in
f 10

let x = 1 in ...   ⟹   outer env = {x:1}
f = fun y -> x+y   ⟹   closure ({x:1}, λy. x+y)   (* x:1 frozen in closure *)
let x = 2 in ...   ⟹   outer env = {x:2, x:1}     (* does NOT change closure *)
f 10               ⟹   evaluate (x+y) in {y:10, x:1}  =  11
                        (* uses closure's env, not outer env *)

let x = 1 in ...   ⟹   outer env = {x:1}
f = fun y -> x+y   ⟹   closure (•, λy. x+y)       (* no env captured *)
let x = 2 in ...   ⟹   outer env = {x:2, x:1}
f 10               ⟹   evaluate (x+y) in {y:10, x:2, x:1}  =  12
                        (* uses caller's env — x:2 is the first match *)

9.13 Interpreter Exampl 1: Substitution Based Interpreter🔗

OCaml REPL

type id = string;;
 type num = int;;

 type exp =
 | Ident of id
 | Num of num
 | Plus of exp * exp
 | Let of id * exp * exp
 ;;

 (*  substitute x in e2 with e1  *)

 let rec subst x e1 e2 =
          match e2 with
    | Ident y -> if x=y then e1 else e2
    | Num c -> Num c
    | Plus(el,er) -> Plus(subst x e1 el, subst x e1 er)
    | Let(y,ebind,ebody) ->
      if x=y then Let(y, subst x e1 ebind, ebody)
      else Let(y, subst x e1 ebind, subst x e1 ebody)
 ;;

 let rec eval exp =
    match exp with
    |Num n -> n
    |Plus(e1,e2)->
      let n1 = eval e1 in
      let n2 = eval e2 in
      let n3 = n1 + n2
      in n3
    |Let (x,e1,e2) ->
      let e2' = subst x e1 e2 in
      let v2 = eval e2' in v2
      |_->failwith "error 1"
 ;;
 (* let x = 10 in x + 10 *)
 eval (Let("x", Num 10, Plus(Ident "x",Num 10)));;

 (* let x = 10 in let y = x+1 in x+y;; *)
 let e2 =(Let("y", Plus(Ident "x", Num 1),
                  Plus(Ident "x", Ident "y")));;
 eval (Let("x", Num 10, e2));;
 ;;

[Output]
type id = string
type num = int
type exp =
    Ident of id
  | Num of num
  | Plus of exp * exp
  | Let of id * exp * exp
val subst : id -> exp -> exp -> exp = <fun>
val eval : exp -> num = <fun>
- : num = 20
val e2 : exp =
  Let ("y", Plus (Ident "x", Num 1), Plus (Ident "x", Ident "y"))
- : num = 21

9.14 Interpreter Exampl 2: Environment Based Intepreter🔗

OCaml REPL

type id = string

 (* v ::= n | true | false *)
 type value = Int of int | Bool of bool

 (*  e ::= x
           | v
           | e + e
           | let x = e in e
           | eq0 e
           | if e then e else e
   *)

 type exp =
    | Ident of id
    | Val of value
    | Plus of exp * exp
    | Let of id * exp * exp
    | Eq0 of exp
    | GT of exp * exp
    | If of exp * exp * exp

 type env = (id * value) list

 let extend env x v = (x, v) :: env

 let rec lookup env x =
    match env with
    | [] -> failwith "Undefined variable"
    | (y, v) :: env' -> if x = y then v else lookup env' x

 let rec eval env e =
    match e with
    | Ident x -> lookup env x
    | Val v -> v
    | Plus (e1, e2) -> (
        let v1 = eval env e1 in
        let v2 = eval env e2 in
        match (v1, v2) with
        | Int n1, Int n2 ->
            let n3 = n1 + n2 in
            Int n3
        | _ -> failwith "Type Error")
    | Let (x, e1, e2) ->
        let v1 = eval env e1 in
        let env' = extend env x v1 in
        let v2 = eval env' e2 in
        v2
    | Eq0 e1 -> (
        match eval env e1 with
        | Int n -> if n = 0 then Bool true else Bool false
        | _ -> failwith "Type Error")
    | GT (e1, e2) -> (
        match (eval env e1, eval env e1) with
        | Int v1, Int v2 -> if v1 >= v2 then Bool true else Bool false
        | _ -> failwith "Type Error")
    | If (e1, e2, e3) -> (
        match eval env e1 with
        | Bool b -> if b then eval env e2 else eval env e3
        | _ -> failwith "Type Error")
 ;;

 (* 20 + x *)
 eval [ ("x", Int 100) ] (Plus (Val (Int 20), Ident "x"));;

 (* let x = 10 in let x = x+ 1 in x+2;;*)
 eval [] (Let("x", Val(Int 10), Let("x", Plus(Ident "x", Val(Int 1)), Plus(Ident "x", Val(Int 2)))));;

 (*let x = 10 in Let y = x+ 1 in x+y;;\n\*)
 eval [] (Let("x", Val(Int 10), Let("y", Plus(Ident "x", Val(Int 1)), Plus(Ident "x", Ident "y"))));;

 (* let x = let x = 10 in x+1 in x+ 2*)
 eval []   (Let("x", (Let("x", Val(Int 10), Plus(Ident "x", Val(Int  1)))), Plus(Ident "x", Val(Int 2))));;

 (* if 4+2 = 0 then 100 else 200*)
 eval [] (If(Eq0 (Plus(Val(Int 4), Val(Int 2))), Val(Int 100), Val(Int 200)));;

 (* if 4+2 >= 6  then 100 else 200*)
 eval [] (If(GT (Plus(Val(Int 4), Val(Int 2)), Val(Int 6)), Val(Int 100), Val(Int 200)));;

[Output]
type id = string
type value = Int of int | Bool of bool
type exp =
    Ident of id
  | Val of value
  | Plus of exp * exp
  | Let of id * exp * exp
  | Eq0 of exp
  | GT of exp * exp
  | If of exp * exp * exp
type env = (id * value) list
val extend : ('a * 'b) list -> 'a -> 'b -> ('a * 'b) list = <fun>
val lookup : ('a * 'b) list -> 'a -> 'b = <fun>
val eval : (id * value) list -> exp -> value = <fun>
- : value = Int 120
- : value = Int 13
- : value = Int 21
- : value = Int 13
- : value = Int 200
- : value = Int 100

9.15 Interpreter vs. Compiler🔗

int main() {
  int a = 1 + 2 + 3 + 4;
  return a;
}

% gcc -c a.c -o a.o
% objdump -d a.o

push   %rbp
mov    %rsp,%rbp
movl   $0xa,-0x4(%rbp)
mov    -0x4(%rbp),%eax
pop    %rbp
ret

9.16 Summary🔗

• Operational semantics defines program meaning via inference rules that specify how expressions evaluate to values

• A judgment e ⇒ v (or A; e ⇒ v with environments) holds iff a proof (derivation tree) can be constructed

• Axioms have no hypotheses; rules derive conclusions from proved hypotheses

• Derivations are trees built by goal-directed search; they have the same shape as interpreter call trees

• Substitution semantics replaces variables with values in the AST; environment semantics maintains an explicit map and looks up variables

• An environment is a partial function from identifiers to values, implemented as an association list

• Closures pair a function with the environment at its definition site, enabling lexical scoping

• Lexical scoping: free variables resolved in the definition environment; dynamic scoping: free variables resolved in the call environment
